| 起源の場所: | 中国 |
|---|---|
| ブランド名: | BOTO |
| 証明: | MIL STD GB JIS JEDEC IEC ISO |
| モデル番号: | B-TH-48L |
| 最小注文数量: | 1セット |
| 価格: | negotiable |
| パッケージの詳細: | 木の場合 |
| 受渡し時間: | 15days |
| 支払条件: | L/C、T/T、ウェスタン・ユニオン |
| 供給の能力: | 1000pc/month |
| モデル: | B-TH-48L | 動力源: | AV:220V/380V 50/60Hz |
|---|---|---|---|
| 内部薄暗くしなさい: | 40x40x30 | 外的薄暗くしなさい: | 60x80x107 |
| 力: | 1.5KW~2.5KW | 相対湿度: | -60℃~150℃ （100℃） |
| 相対湿度の範囲: | 20%~98%RH | 加熱の時間: | About3℃/min |
| 温度偏差: | ±1.0℃ | 臨時雇用者Fluctudtiont: | ±0.5℃ |
1. Small size, special design and overlapping, not occupying planar space, suitable for laboratory use.
2. Low power consumption, energy saving and consumption reduction; low noise, low radiation, green environmental protection.
3. High efficiency, communication mode using Qualcomm software F4 controller to complete a variety of tests at the same time.
4. Both sides are equipped with side tests. Holes, easy to operate.
5. Multiple safety protection, refrigerant high voltage protection, compressor overload protection, current overload protection, overtemperature protection, leakage protection.
Design Standard:
GB/T2423/5170/10586, JIS C60068, ASTM D4714, CNS3625/12565/12566
Uses:
This equipment can simulate different environment condition. It's appropriate for testing material performance, such as resist heat, resist dry,resist humidity and resist cold. That can define performance of material.
Character:
1.Use the high precision microcomputer touch temperature and humidity controller with high stability of platinum resistance to temperature and wind speed in the circulatory system of temperature and humidity test.
2.control temperature&humidity well-distributed, precisely and steady.
3. Completely independent system separate for testing in high temperature, low temperature and constant temperature&humidity environment.
Application:
Table type constant temperature and humidity test box box using CNC machine processing molding, beautiful and elegant, novel and adopt no reaction handle, easy to operate.
The inner chamber is made of imported advanced stainless steel (SUS304) mirror plate or 304B argon arc welding, and the outer chamber is sprayed with A3 steel plate. Microcomputer temperature and humidity controller, temperature and humidity control accurate and reliable.
Large observation window with lights to keep the box bright, and the use of double glass, clear observation box at any time. An independent temperature limit alarm system is set, which automatically interrupts when the temperature exceeds the limit, ensuring the safe operation of the experiment without accidents. The left side of the table type constant temperature and humidity test box is equipped with a test hole with a diameter of 50mm, which can be used for external test power cable or signal cable. The bottom of the machine adopts high quality fixed PU movable wheel.
Standard Compliance:
This product meets the requirements of GB/T2423.1-2001 GB/T2423.3-1993 GB/T2423.2-2001 and other national standards, as well as other relevant standards.
Features:
1. Small size, special design and overlapping, not occupying planar space, suitable for laboratory use.
2. Low power consumption, energy saving and consumption reduction; low noise, low radiation, green environmental protection.
3. High efficiency, communication mode using Qualcomm software F4 controller to complete a variety of tests at the same time.
4. Both sides are equipped with side tests. Holes, easy to operate.
5. Multiple safety protection, refrigerant high voltage protection, compressor overload protection, current overload protection, overtemperature protection, leakage protection.
Product specification:
| Name | Small high and low temperature test chamber | Table type constant temperature and humidity test chamber | ||||
| Model | dry heat | B-T-107(A-D) | B-T-48L (A~D) | |||
| damp and hot | B-TH-48L (A-D) | |||||
| Internal Dim | 30.5x23x29 | 40x40x30 | ||||
| External Dim(W*H*D) | 53x68x72 | 60x80x107 | ||||
| Relative Humidity | ‘-40℃(-60℃)-130℃(100℃) (A:0℃ B:-20℃ C:-40℃ D:-60℃) | ’7.081- -60℃~150℃(100℃) (A:0℃ B:-20℃ C:-40℃ D:-60℃ |
||||
| Relative humidity Range | 20%~98%RH | |||||
| heat-up time | About3℃/min | |||||
| Pull down time | About0.7~1℃/min | |||||
| Temp Fluctudtiont | ±0.5℃ | |||||
| Temp Uniformity | ±1.0℃ | |||||
| Temp Deviation | ±1.0℃ | |||||
| Power Source | AV:220V/380V 50/60Hz | |||||
| Power(KW) | 1KW~2KW | 1.5KW~2.5KW | ||||
About us:
Certifications:
Packaging & Shipping
Packing:
1. Fully packed with PE film;
2. Wooden box;
3. Machine is fastened to the corners of the containers;
4. If export to European countries, the wooden box will be fumigated;
5. Customized package is available.
Shipping:
FAQ:
1. Are a manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?
-Yes, we are manufacturer of Small High And Low Femperafure Fest Chamber. Every machine from our factory has a 12 months product warranty.If your machine doesn’t work, you can send E-mail to us and we will try our best to find the problem by email or video chat if neccesary. After confirmation of the problem, we can send you new spare parts or provide on-site repair.
2. What’s the delivery term?
-If there is no stock, normally, the delivery time is 15-25 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
3. what about the products' quality?
-Each batch of parts is done quality sampling inspection before into the warehouse, and Each product before delivery is tested by the national authoritative third-party inspection agency.
4.what about the packing of equipment?
-We use Standard Export Plywood Case to Protect it from rust during the long time shipping with the plastic film and protect its corners with the foam.
